Utility and Transfer Panels

Introduction to Utility and Transfer Panels

As one of the world’s first manufacturers of transfer panels, Suncombe Transfer Panels have been produced by Suncombe for over 50 years. The panels are used for service entry, utility entry, CIP and SIP routing and also for utility piping and control outside of the clean area.

This principle removes the equipment and instruments from the production areas by locating them in service areas, providing additional production area space and allowing maintenance outside of production areas.

UTILITY PANELS TRANSFER PANELS
Speak to one of our specialists

Speak to one of our specialists

CONTACT US

Build demonstration videos

Key Features


HYGIENIC DESIGN

Our Transfer Panels have radius edges and no exposed threads


ERGONOMICS

180° Swing bends


EQUIPMENT

Primarily built to ASME BPE SF1 and SF4 for hygienic services, suitable materials and piping standards are used for other utilities

CERTIFIED SURFACE FINISHES

Wetted parts surface descaled and bead removed, non wetted parts satin polished


UTILITIES

Glycol, oxygen, WFI, PW

STANDING AND MOUNTING

Z-clips, Switches for swing bend position, Thru-wall mounting versions

ATEX

ATEX versions are available for solvent use and/or aqueous use in zoned areas.

STRUCTURAL ANALYSIS

Standard configurations and custom designed, the transfer panels are manufactured from 316 stainless steel

CONNECTION METHODOLOGY

Dry break QC, Process fitting Tri-clamps and Weld ends


SPILL CONTAINMENT

Sinks and Tundishes allow for free draining

CONTROLLED SEPARATION

Transfer bosses, pipe spec changes and surface finishes

INTEGRATION

Integration with Suncombe CIP and process systems

ENGRAVING AND BRANDING

Engravings/Brandings of your logo are optional if required

Manufacturing Standards

Business Practices

Welding Standards

BS EN 10204 – 3.1 BS EN ISO 9606-1:2013 BS EN ISO 15614-1:2004+A2:2012
